CAUTION / NOTICE / HINT

NOTICE:

Some satellite radio broadcasts require payment. A contract must be made between a satellite radio company and the user. If the contract expires, it will not be possible to listen to the broadcast.

PROCEDURE

1.

CHECK SATELLITE RADIO

(a) Check radio condition.

Result

Result

Proceed to

Broadcast cannot be selected.

A

Broadcast can be selected, but selection cannot be memorized.

B

A

PROCEED TO NEXT SUSPECTED AREA SHOWN IN PROBLEM SYMPTOMS TABLE

B

2.

CHECK SATELLITE RADIO

(a) Check the number of preset channels.

OK:

36 channels have already been preset.

OK

END (ONLY 36 CHANNELS CAN BE PRESET)

NG

3.

CHECK BATTERY

(a) Check if the battery was replaced.

OK:

Battery was not replaced.

OK

PROCEED TO NEXT SUSPECTED AREA SHOWN IN PROBLEM SYMPTOMS TABLE

NG

4.

ADD PRESET CHANNEL INTO MEMORY AGAIN

(a) Check if the preset channels that have been cleared can be added into memory again.

OK:

Preset channels can be added into memory.

OK

END

NG

PROCEED TO NEXT SUSPECTED AREA SHOWN IN PROBLEM SYMPTOMS TABLE
