COMPONENTS

COMPONENTS

COMPONENTS

COMPONENTS

REMOVAL

1. REMOVE FRONT FENDER LINER LH

2. REMOVE FRONT FENDER LINER RH

3. REMOVE FRONT BUMPER COVER

4. REMOVE REAR BUMPER COVER (2)

5. REMOVE NO. 1 ULTRASONIC SENSOR RETAINER

REMOVE NO. 1 ULTRASONIC SENSOR RETAINER

  1.  Remove the No. 1 ultrasonic sensor retainer as shown in the illustration

6. REMOVE NO. 1 ULTRASONIC SENSOR

REMOVE NO. 1 ULTRASONIC SENSOR

  1.  Disconnect the connector and remove the No. 1 ultrasonic sensor.

INSPECTION

1. INSPECT NO.1 ULTRASONIC SENSOR

INSPECT NO.1 ULTRASONIC SENSOR

  1.  Measure the resistance according to the value(s) in the table below.

Standard resistance

Standard resistance

If the result is not as specified, replace No.1 ultrasonic sensor

INSTALLATION

1. INSTALL NO. 1 ULTRASONIC SENSOR

  1.  Connect the connector and install the No. 1 ultrasonic sensor.

2. INSTALL NO. 1 ULTRASONIC SENSOR RETAINER

  1.  Install the No. 1 ultrasonic sensor retainer.

3. INSTALL REAR BUMPER COVER (3)

4. INSTALL FRONT BUMPER COVER

5. INSTALL FRONT FENDER LINER LH

6. INSTALL FRONT FENDER LINER RH
