Toyota Corolla Repair Manual: Replacement

Toyota Corolla Repair Manual: Replacement

Hint

: components:

1. Precaution

2. Disconnect battery negative terminal

3. Remove horn button assy

  1. Place the front wheels facing straight ahead.
  2.  using a torx socket wrench (t30), loosen the 2 torx screws until the groove along the screw circumference catches on the screw case.

  1. Pull out the horn button assy from the steering wheel assy.
  2.  using a screwdriver, release the lock part of each airbag connector and disconnect the 2 airbag connectors.

4. Inspect horn button assy

5. Install horn button assy

  1.  connect the airbag connectors and horn connector.
  2.  install the horn button assy after confirming that the circumference groove of the torx screws is caught on the screw case.
  3.  using a torx socket wrench (t 30), install the 2 screws.

    Torque: 8.8 Nvm (90 kgfvcm, 78 in.Vlbf)

6. Inspect srs warning light

Disposal
Hint: when scrapping vehicle equipped with an srs or disposing of a horn button assy, always first deploy the airbag in accordance with the procedure described below. If any abnormality occurs i ...
