Removal and Installation

Warning:

Do not touch bulb while it is lit or right after being turned off. Burning may result.

Caution:

Do not touch glass surface of the bulb with bare hands or allow oil or grease to get on it to prevent damage to bulb.

  1. Release the tab (b) to open the lens.

: Front


  1. Remove the trunk room bulb (2).
  2. Release tab (c), then pull trunk room lamp (1) down to remove.
  3. Disconnect the harness connector (a) from the trunk room lamp.

Installation


Installation

Installation is in the reverse order of removal.

Bulb Replacement

Warning:

Do not touch bulb while it is lit or right after being turned off. Burning may result.

Caution:

Do not touch glass surface of the bulb with bare hands or allow oil or grease to get on it to prevent damage to bulb.

  1. Release the tab to open the lens.
  2. Remove bulb from trunk room lamp.
  3. Install bulb to trunk room lamp.
  4. Close lens.
