Bcm (body control system) (with intelligent key system)

BCM (BODY CONTROL SYSTEM) (WITH INTELLIGENT KEY SYSTEM) : Diagnosis Procedure

Regarding Wiring Diagram information, refer to BCS-51, "Wiring Diagram".

1.CHECK FUSES AND FUSIBLE LINK

Check that the following fuses and fusible link are not blown.

Is the fuse blown?


Is the fuse blown? YES >> Replace the blown fuse or fusible link after repairing the affected circuit.

NO >> GO TO 2.

2.Check power supply circuit

  1. Disconnect BCM connector M85.
  2. Check voltage between BCM connector M85 and ground.

Is the inspection result normal?


Is the inspection result normal? Yes >> go to 3.

No >> repair harness or connector.

3.Check ground circuit

Check continuity between bcm connector m85 and ground.

Is the inspection result normal?


Is the inspection result normal? YES >> Inspection End.

NO >> Repair harness or connector.

Bcm (body control system) (without intelligent key system)

BCM (BODY CONTROL SYSTEM) (WITHOUT INTELLIGENT KEY SYSTEM) : Diagnosis Procedure

Regarding Wiring Diagram information, refer to BCS-111, "Wiring Diagram".

1.Check fuses and fusible link

Check that the following fuses and fusible link are not blown.

Is the fuse blown?


Is the fuse blown? Yes >> replace the blown fuse or fusible link after repairing the affected circuit.

No >> go to 2.

2.Check power supply circuit

  1. Turn ignition switch OFF.
  2. Disconnect bcm connectors.
  3. Check voltage between bcm connector and ground.

Is the inspection result normal?


Is the inspection result normal? YES >> GO TO 3.

NO >> Repair harness or connector.

Is the inspection result normal? Yes >> go to 3.

No >> repair harness or connector.

3.Check ground circuit

Check continuity between bcm connector and ground.

Is the inspection result normal?


Is the inspection result normal? YES >> Inspection End.

NO >> Repair harness or connector.
