Description

Transmits switch operation signal to moonroof motor and sunshade motor assembly.

Diagnosis Procedure

Regarding Wiring Diagram information, refer to RF-17, "Wiring Diagram".

1.CHECK MOONROOF SWITCH INPUT SIGNAL

  1.  Turn ignition switch ON.
  2.  Check voltage between moonroof motor assembly harness connector and ground.

Check moonroof switch input signal

Is the inspection result normal? YES >> Inspection End.

NO >> GO TO 2.

2.CHECK MOONROOF SWITCH CIRCUIT

  1.  Turn ignition switch OFF.
  2.  Disconnect moonroof motor assembly connector and moonroof switch connector.
  3.  Check continuity between moonroof motor assembly harness connector and moonroof switch harness connector.

Check moonroof switch circuit

  1. Check continuity between moonroof motor assembly harness connector and ground.

Check moonroof switch circuit

Is the inspection result normal? YES >> GO TO 3.

NO >> Repair or replace the harness.

3.CHECK MOONROOF SWITCH GROUND CIRCUIT

Check continuity between moonroof switch harness connector and ground.

Check moonroof switch ground circuit

Is the inspection result normal? YES >> GO TO 4.

NO >> Repair or replace the harness.

4.CHECK MOONROOF SWITCH

Check moonroof switch.

Refer to RF-32, "Component Inspection".

Is the inspection result normal? YES >> GO TO 5.

NO >> Replace moonroof switch. Refer to RF-64, "Removal and Installation".

5.CHECK INTERMITTENT INCIDENT

Refer to GI-41, "Intermittent Incident".

>> Inspection End.

Component Inspection

MOONROOF SWITCH

1. CHECK MOONROOF SWITCH

  1.  Turn ignition switch OFF.
  2.  Disconnect moonroof switch.
  3.  Check continuity between moonroof switch terminals.

Check moonroof switch

Is the inspection result normal? YES >> Moonroof switch is OK.

NO >> Replace moonroof switch. Refer to RF-64, "Removal and Installation".
