DTC Logic

DTC DETECTION LOGIC

DTC Display Item Malfunction detected condition Possible causes
C1140 ACTUATOR RLY When a malfunction is detected in actuator relay.
  • Harness or connector
  •  ABS actuator and electric unit (control unit)
  •  Fusible link
  •  Battery power supply syste

DTC CONFIRMATION PROCEDURE

1.CHECK SELF-DIAGNOSTIC RESULT

With CONSULT.

  1.  Turn ignition switch OFF to ON.
  2.  Perform self-diagnostic result.

Is DTC C1140 detected? YES >> Proceed to diagnosis procedure. Refer to BRC-92, "Diagnosis Procedure".

NO >> Inspection End.

Diagnosis Procedure

Regarding Wiring Diagram information, refer to BRC-57, "Wiring Diagram".

1.CONNECTOR INSPECTION

  1.  Turn ignition switch OFF.
  2.  Disconnect ABS actuator and electric unit (control unit) connectors.
  3.  Check connectors and terminals for deformation, disconnection, looseness or damage.

Is the inspection result normal? YES >> GO TO 2.

NO >> Repair or replace as necessary.

2.CHECK ABS ACTUATOR AND ELECTRIC UNIT (CONTROL UNIT) BATTERY POWER SUPPLY

Check voltage between ABS actuator and electric unit (control unit) connector E125 terminals 1, 25 and ground.

Check ABS actuator and electric unit (control unit) battery power supply

Is the inspection result normal? YES >> GO TO 3.

NO >> Repair or replace malfunctioning components.

3.CHECK ABS ACTUATOR AND ELECTRIC UNIT (CONTROL UNIT) GROUND CIRCUIT

Check continuity between ABS actuator and electric unit (control unit) connector E125 terminals 13, 38 and ground.

Check ABS actuator and electric unit (control unit) ground circuit

Is the inspection result normal? YES >> Replace ABS actuator and electric unit (control unit). Refer to BRC-136, "Removal and Installation".

NO >> Repair or replace malfunctioning components.
