Mazda 3 Service Manual: Seat Weight Sensor Control Module Removal/Installation [Two Step Deployment Control System]

CAUTION:

  • When the seat weight sensor control module is replaced with a new one, perform the seat weight sensor calibration using the M–MDS..

1. Switch the ignition to off.

2. Disconnect the negative battery cable and wait for1 min or more

..

3. Disconnect the connectors.


4. Remove the seat weight sensor control module from the bracket by lifting the tab in the direction of the arrow.

5. Install in the reverse order of removal.

6. Switch the ignition to ON.

7. Verify that the air bag system warning light illuminates forapprox. 6 s

and goes out.
