Mazda 3 Service Manual: Clock Spring Adjustment

Mazda 3 Service Manual: Clock Spring Adjustment

NOTE:

  • The adjustment procedure is also specified on the caution label of the clock spring.

1. Set the front wheels straight ahead.

CAUTION:

  • The clock spring will break if over–wound. Do not forcibly turn the clock spring.

2. Turn the clock spring clockwise until it stops.


3. Turn the clock spring counterclockwise2 3/4 turns

.


4. Align the mark on the clock spring with the mark on the outer housing.
