Kia Soul: Compressor Components

Kia Soul: Compressor Components

1. Clutch Bolt
2. Limiter Bolt
3. Limiter & Hub Assembly
4. Snap Ring
5. Pulley
6. Compressor Assembly
7. Electric Control Valve (ECV)

Compressor Description
The compressor is the power unit of the A/C system. It is located on the side of engine block and driven by a V-belt of the engine. The compressor changes low pressure and low temperatur ...
Compressor Removal
1. If the compressor is marginally operable, run the engine at idle speed, and let the air conditioning work for a few minutes, then shut the engine off. ...
