Chevrolet Cruze Repair Manual: Driver or Passenger Seat Side Inflatable Restraint Module Replacement

Chevrolet Cruze Repair Manual: Driver or Passenger Seat Side Inflatable Restraint Module Replacement

Warning: Refer to SIR Inflator Module Handling and Storage Warning

Warning: Refer to SIR Inflator Module Handling and Storage Warning in the Preface section.

Warning: Following the deployment of a side impact air bag, inspect the following parts for damage. Replace these parts if necessary:

  • The seat cushion frame
  • The seat recliner, if equipped
  • The seat adjuster
  • The seat back frame

Failure to do so may cause future personal injury.

Preliminary Procedure

Disable the SIR system. Refer to SIR Disabling and Enabling.

Front Seat Back Trim

Front Seat Side Inflatable Restraint Module Nut (Qty: 2)

Caution: Refer to Fastener Caution in the Preface section.

Tighten 4 N·m (36 lb in)

Front Seat Side Inflatable Restraint Module Assembly

Tip

Disconnect the electrical connector.
